WATER SOLENOID VALVES

If you cannot find what you need here then choose a link below(81):

1) Search Tables on Main HOME Page - CLICK HERE

Solenoid Valves for water is used to switch on or off the flow of water in a pipeline by means of electricity. This is usually done by a remote switch by hand or electronic controller, like a PLC (Programmeble Logic Controller), Temperature controller, Pressure transducer, Magflow flow or Impeller volumetric meter.

Water solenoid Valves can also be used for Auto Changeover to Municipal on power failure or Mains water Change when load shedding takes place from Borehole to Mains Municipal supply line. The same solenoid valves can also be used to change the water feed from a Solar or gas Geyser to your house.

The solenoid is the coiled wire winding(usually in a Black resin mould) with a centre hole that fits over a valve body stem tube. When Electricity is applied to the coil a magnitism in the coil centre hole will pull up a Core inside the stem tube(over wich it fits) to either open or close the solenoid Valve.

Normally Closed / Normally Open Solenoid Valves

The solenoid valve can be bought as normally closed or normally open.(Normally-refers to the state of the valve when de-energised/without any electric power applied/Off)

A Normally closed Valve is Closed without Power(usually with a mechanical spring). When you apply power to the coil, the plunger or daiphram sealing it closed lifts up by magnitism and assisted mechanisms and thus opens the valve and flow. Swithcing off the power will cut off the magnitism and drops the plunger or Diaphragm with a spring to close it.

ANormally Open Valve is open without power(With a mechanical spring).When you apply power to the coil, the plunger or daiphram thats open will now be forced down with Magnitism to close the valve/flow. Swithcing off the power will cut off the magnitism andthe mechanical spring will forceth plunger or diaphragm upwards and open the valve or flow.

Direct acting plunger valves of 1/8" and 1/4" the function works like above. In larger diaphra valves usually from 1/2" upward, there is addtional mechanisms to assist the small coils in opening or closing the larger valves by pilot or assisted lift.

We offer these Solenoids in Sizes:1/8 inch, 1/4 inch, 3/8 ich,1/2 inch, 3/4 inch inch1 inch1.25 inch1.5 inches, and 2 inches.

Valve Materials is Bodies in Brass, stainless Steel 304 and Stainless steel 316 with Viton or PTFE Seals.

PLM222 Mini Brass Series, Direct Acting (NC) Solenoid Valve

1/4" PLM222 Series - 2/2 N/Closed, Direct Acting Solenoid Valve. The Valve Body is made of BRASS. Seals are VITON - up to 140 Deg C. Orifice 1mm, 2mm or 2.5mm. The Operating Pressure Range depends on the orifice size and voltage, see PDF data sheet. (Click the "View PDF" below for complete information)


View PDF data sheet for specific information.
PLM222 Mini Brass Series, Direct Acting (NC) Solenoid Valve

1/4" PLM222 Series - 2/2 N/Closed, Direct Acting Solenoid Valve. The Valve Body is made of BRASS. Seals are VITON - up to 140 Deg C. Orifice 1mm, 2mm or 2.5mm. The Operating Pressure Range depends on the orifice size and voltage, see PDF data sheet. (Click the "View PDF" below for complete information)


View PDF data sheet for specific information.

1/4" BSP, Brass & VITON, Orf: 1mm, 0 to 15/20 Bar(C1010DX coil excl)
PART NO : PLM222BH01S02V
SIZE/DESCRIPTION:
1/4" BSP, Brass & VITON, Orf: 1mm, 0 to 15/20 Bar(C1010DX coil excl)

PRICE FROM: R 459.75 (Coil Excluded)
QUANTITY:


QUANTITY:
PART NO : PLM222BH02S02V
SIZE/DESCRIPTION:
1/4" BSP, Brass & VITON, Orf: 2mm, 0 to 10/13 Bar(C1010DX coil excl)

PRICE FROM: R 459.75 (Coil Excluded)
QUANTITY:


QUANTITY:
PART NO : PLM222BH025S02V
SIZE/DESCRIPTION:
1/4" BSP, Brass & VITON, Orf: 2.5mm, 0 to 6/10 Bar(C1010DX coil excl)

PRICE FROM: R 459.75 (Coil Excluded)
QUANTITY:


QUANTITY:

P2W22 BRASS Series, Diaphragm Assisted Lift (N.C), Solenoid Valves

P2W22 Series - 2/2 N/Closed Assisted Lift Diaphragm Valves. The Valve Body is made of BRASS. Seals available is NBR, VITON and EPDM. The Operating pressure Range is 0 to 10 Bar. Suitable for Gravity feed applications (Zero) 0 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. The only further requirement is viscosity below 40 Centistokes. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available.


View PDF data sheet for specific information.
P2W22 BRASS Series, Diaphragm Assisted Lift (N.C), Solenoid Valves

P2W22 Series - 2/2 N/Closed Assisted Lift Diaphragm Valves. The Valve Body is made of BRASS. Seals available is NBR, VITON and EPDM. The Operating pressure Range is 0 to 10 Bar. Suitable for Gravity feed applications (Zero) 0 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. The only further requirement is viscosity below 40 Centistokes. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available.


View PDF data sheet for specific information.

1/2" BSP, Brass & Viton, 0 to 10Bar (C14DX coil excl)
PART NO : P2W22BH15S04
SIZE/DESCRIPTION:
1/2" BSP, Brass & Viton, 0 to 10Bar (C14DX coil excl)

PRICE FROM: R 1227.00
QUANTITY:


QUANTITY:
PART NO : P2W22BH20S06
SIZE/DESCRIPTION:
3/4" BSP, Brass & Viton, 0 to 10Bar (C14DX coil excl)

PRICE FROM: R 1367.60
QUANTITY:


QUANTITY:
PART NO : P2W22BH25S10
SIZE/DESCRIPTION:
1" BSP, Brass & Viton, 0 to 10Bar (C14DX coil excl)

PRICE FROM: R 1895.60
QUANTITY:


QUANTITY:

PM-17 Series , 1/2" 2/2, N/Closed, Servo Assisted Solenoid Valve

1/2" PM-17 Series - 2/2 N/Closed Servo Assisted Solenoid Valves. The Valve Body is made of Polyoxymethylene. EPDM Seal, Orifice 10 mm.The Operating pressure Range is 0.2 to 8 Bar. Only Available in 24VDC. Suitable for Water, Air & Some Chemicals. (Click the "View PDF" below for complete information)


View PDF data sheet for specific information.
PM-17 Series , 1/2" 2/2, N/Closed, Servo Assisted Solenoid Valve

1/2" PM-17 Series - 2/2 N/Closed Servo Assisted Solenoid Valves. The Valve Body is made of Polyoxymethylene. EPDM Seal, Orifice 10 mm.The Operating pressure Range is 0.2 to 8 Bar. Only Available in 24VDC. Suitable for Water, Air & Some Chemicals. (Click the "View PDF" below for complete information)


View PDF data sheet for specific information.

1/2'' POM Sol Valve, 2/2 N/C, EPDM seal, Orf 10mm, 0.2-8 Bar 24VDC
PART NO : PM-17
SIZE/DESCRIPTION:
1/2'' POM Sol Valve, 2/2 N/C, EPDM seal, Orf 10mm, 0.2-8 Bar 24VDC

PRICE FROM: R 308.10 (With 24VDC Coil Included)
QUANTITY:


QUANTITY:

PGH22 Brass Series, N/Closed, Direct Acting Solenoid Valve

PGH22 Brass Series - 2/2 N/Closed Direct Acting Solenoid Valve. The Valve Body is made of Brass. Seals available is VITON. Orifice 4mm. The operating depends on orifice and voltage - see PDF for more technical specs.


View PDF data sheet for specific information.
PGH22 Brass Series, N/Closed, Direct Acting Solenoid Valve

PGH22 Brass Series - 2/2 N/Closed Direct Acting Solenoid Valve. The Valve Body is made of Brass. Seals available is VITON. Orifice 4mm. The operating depends on orifice and voltage - see PDF for more technical specs.


View PDF data sheet for specific information.

1/4" BSP, Normally Closed, Brass & Viton, Orf: 4mm, 0 to 10(AC) 4(DC) Bar (C9D Coil excl)
PART NO : PGH22BH04S02V
SIZE/DESCRIPTION:
1/4" BSP, Normally Closed, Brass & Viton, Orf: 4mm, 0 to 10(AC) 4(DC) Bar (C9D Coil excl)

PRICE FROM: R 680.95 (Coil Excluded)
QUANTITY:


QUANTITY:

PGH23 Brass Series, N/Open, Direct Acting Solenoid Valve

PGH23 Brass Series - 2/2 N/Open Direct Acting Solenoid Valve. The Valve Body is made of Brass. Seals available is VITON. Orifice 2mm. The operating depends on orifice and voltage - see PDF for more technical specs.


View PDF data sheet for specific information.
PGH23 Brass Series, N/Open, Direct Acting Solenoid Valve

PGH23 Brass Series - 2/2 N/Open Direct Acting Solenoid Valve. The Valve Body is made of Brass. Seals available is VITON. Orifice 2mm. The operating depends on orifice and voltage - see PDF for more technical specs.


View PDF data sheet for specific information.

1/4" BSP, Normally Open, Brass & Viton, Orf: 2mm, 0 to 15 Bar (C9D Coil excl)
PART NO : PGH23BH02S02V
SIZE/DESCRIPTION:
1/4" BSP, Normally Open, Brass & Viton, Orf: 2mm, 0 to 15 Bar (C9D Coil excl)

PRICE FROM: R 881.15 (Coil Excluded)
QUANTITY:


QUANTITY:

PDS22BH Series, N/Closed, Pilot Operated, High Pressure Brass Solenoid Valves

PDS22BH Series - 2/2 N/Closed Pilot Operated, High Pressure Solenoid Valves. The Valve Body is made of Brass. Seals available is VITON. The Operating pressure Range is 0,3 to 16 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses which is compatible with Brass and Viton. The only further requirement is viscosity below 40 Centistokes and a Minimum available pressure of 0,3 Bar(3 Meter Head). Thus not suitable for Gravity feed applications. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available.


View PDF data sheet for specific information.
PDS22BH Series, N/Closed, Pilot Operated, High Pressure Brass Solenoid Valves

PDS22BH Series - 2/2 N/Closed Pilot Operated, High Pressure Solenoid Valves. The Valve Body is made of Brass. Seals available is VITON. The Operating pressure Range is 0,3 to 16 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses which is compatible with Brass and Viton. The only further requirement is viscosity below 40 Centistokes and a Minimum available pressure of 0,3 Bar(3 Meter Head). Thus not suitable for Gravity feed applications. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available.


View PDF data sheet for specific information.

1/2" BSP Brass & VITON, Normally Closed, 0,5 to 16 Bar (C13 coil excl)
PART NO : PDS22BH15S04
SIZE/DESCRIPTION:
1/2" BSP Brass & VITON, Normally Closed, 0,5 to 16 Bar (C13 coil excl)

PRICE FROM: R 1640.60
QUANTITY:


QUANTITY:
PART NO : PDS22BH20S06
SIZE/DESCRIPTION:
3/4" BSP, Brass & VITON, Normally Closed, 0,5 to 16 Bar (C13 coil excl)

PRICE FROM: R 1861.15
QUANTITY:


QUANTITY:
PART NO : PDS22BH25S10
SIZE/DESCRIPTION:
1" BSP, Brass & VITON, Normally Closed, 0,5 to 16 Bar (C13 coil excl)

PRICE FROM: R 2357.45
QUANTITY:


QUANTITY:
PART NO : PDS22BH32S12
SIZE/DESCRIPTION:
11/4" BSP, Brass & VITON, Normally Closed, 0,5 to 16 Bar (C13 coil excl)

PRICE FROM: R 3592.70
QUANTITY:


QUANTITY:
PART NO : PDS22BH40S14
SIZE/DESCRIPTION:
11/2" BSP, Brass & VITON, Normally Closed, 0,5 to 16 Bar (C13 coil excl)

PRICE FROM: R 4117.95
QUANTITY:


QUANTITY:
PART NO : PDS22BH50S20
SIZE/DESCRIPTION:
2" BSP, Brass & VITON, Normally Closed, 0,5 to 16 Bar (C13 coil excl)

PRICE FROM: R 6104.55
QUANTITY:


QUANTITY:

PDS22SH Series, N/Closed, Pilot Operated, High Pressure SS316 Solenoid Valves

PDS22 Series - 2/2 N/Closed Pilot Operated, High Pressure Solenoid Valves. The Valve Body is made of 316 Stainless Steel. Seals available is NBR, VITON and EPDM. The Operating pressure Range is 0,3 to 16 Bar. The Valve Body is made of 316 Stainless Steel. Seals standard is VITON with NBR and EPDM available on order. The Operating pressure Range is 0,3 to 16 Bar. Because of the Body Material and Viton seals these valves can be used in with different Liquids and gasses with 99% compatibility. These solenoid valves a good for drinking, potable, medical grade and food grade water or other liquids. The only further requirement is viscosity below 40 Centistokes and a Minimum available pressure of 0,3 Bar (3 Meter Head). Not suitable for Gravity feed applications. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available.


View PDF data sheet for specific information.
PDS22SH Series, N/Closed, Pilot Operated, High Pressure SS316 Solenoid Valves

PDS22 Series - 2/2 N/Closed Pilot Operated, High Pressure Solenoid Valves. The Valve Body is made of 316 Stainless Steel. Seals available is NBR, VITON and EPDM. The Operating pressure Range is 0,3 to 16 Bar. The Valve Body is made of 316 Stainless Steel. Seals standard is VITON with NBR and EPDM available on order. The Operating pressure Range is 0,3 to 16 Bar. Because of the Body Material and Viton seals these valves can be used in with different Liquids and gasses with 99% compatibility. These solenoid valves a good for drinking, potable, medical grade and food grade water or other liquids. The only further requirement is viscosity below 40 Centistokes and a Minimum available pressure of 0,3 Bar (3 Meter Head). Not suitable for Gravity feed applications. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available.


View PDF data sheet for specific information.

1/2" SS316 BSP & VITON seal, Normally closed Valve 0,5 to 16 Bar (C13 Coil excl)
PART NO : PDS22SH15S04
SIZE/DESCRIPTION:
1/2" SS316 BSP & VITON seal, Normally closed Valve 0,5 to 16 Bar (C13 Coil excl)

PRICE FROM: R 1930.10
QUANTITY:


QUANTITY:
PART NO : PDS22SH20S06
SIZE/DESCRIPTION:
3/4" SS316 BSP & VITON seal, Normally closed Valve 0,5 to 16 Bar (C13 Coil excl)

PRICE FROM: R 2283.00
QUANTITY:


QUANTITY:
PART NO : PDS22SH25S10
SIZE/DESCRIPTION:
1" One Inch-25mm BSP Normally Closed, SS316 & VITON - 0,5 to 16 Bar (C13 Coil excl)

PRICE FROM: R 2925.45
QUANTITY:


QUANTITY:
PART NO : PDS22SH40S14
SIZE/DESCRIPTION:
11/2" SS316 BSP & VITON seal, Normally closed Valve 0,5 to 16 Bar (C13 Coil excl)

PRICE FROM: R 5652.35
QUANTITY:


QUANTITY:
PART NO : PDS22SH50S20
SIZE/DESCRIPTION:
2" SS316 BSP & VITON seal, Normally closed Valve 0,5 to 16 Bar (C13 Coil excl)

PRICE FROM: R 7392.20
QUANTITY:


QUANTITY:

PQS22 High Pressure BRASS Series, Diaphragm Direct Acting (N.C), Solenoid Valves

PQS22 High Pressure BRASS Series - 2/2 N/Closed Direct Acting Diaphragm Valves. The Valve Body is made of BRASS with standard VITON seal. The Operating pressure Range differs from orifice size and voltage. Suitable for Gravity feed applications (Zero) 0 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. The only further requirement is viscosity below 20 Centistokes.


View PDF data sheet for specific information.
PQS22 High Pressure BRASS Series, Diaphragm Direct Acting (N.C), Solenoid Valves

PQS22 High Pressure BRASS Series - 2/2 N/Closed Direct Acting Diaphragm Valves. The Valve Body is made of BRASS with standard VITON seal. The Operating pressure Range differs from orifice size and voltage. Suitable for Gravity feed applications (Zero) 0 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. The only further requirement is viscosity below 20 Centistokes.


View PDF data sheet for specific information.

1/2" BSP, Normally Closed, Brass & Viton, Orifice: 10mm, 0 to 20Bar(AC)/16Bar(DC) (C13DX coil excl)
PART NO : PQS22BH10S04V
SIZE/DESCRIPTION:
1/2" BSP, Normally Closed, Brass & Viton, Orifice: 10mm, 0 to 20Bar(AC)/16Bar(DC) (C13DX coil excl)

PRICE FROM: R 989.05 (Coil Excluded)
QUANTITY:


QUANTITY:
PART NO : PQS22BH13S04V
SIZE/DESCRIPTION:
1/2" BSP, Normally Closed, Brass & Viton, Orifice: 13mm, 0 to 16Bar(AC)/12Bar(DC) (C13DX coil excl)

PRICE FROM: R 989.05 (Coil Excluded)
QUANTITY:


QUANTITY:
PART NO : PQS22BH16S06V
SIZE/DESCRIPTION:
3/4" BSP, Normally Closed, Brass & Viton, Orifice: 16mm, 0 to 12Bar(AC)/10Bar(DC) (C13DX coil excl)

PRICE FROM: R 1156.85 (Coil Excluded)
QUANTITY:


QUANTITY:
PART NO : PQS22BH20S10V
SIZE/DESCRIPTION:
1" BSP, Normally Closed, Brass & Viton, Orifice: 20mm, 0 to 10Bar(AC & DC) (C13DX coil excl)

PRICE FROM: R 1534.50 (Coil Excluded)
QUANTITY:


QUANTITY:

P5W22 Series, NC, Nylon (PA66) Valves

P5W22 Series - 2/2 N/Closed Direct Lift Diaphragm Solenoid Valves. The Valve Body is made of Nylon (PA66). Standard seals available is NBR, optional seals available is VITON and EPDM. The Operating pressure Range is 0 to Rated MAXIMUM PRESSURE in Datasheet.(Check specific Size and Voltage DC or AC). Suitable for Gravity feed applications(Zero) 0 Bar. Because of the Nylon Body and NBR seal these valves can be used with compatible liquids and gasses. These Valves are Fitted with Large Coils , so please NOTE the POWER CONSUMPTION(see datasheet) and Possible overheating in Direct sunlight. The only further requirement is viscosity below 20 Centistokes. MOUNTING-HORIZONTAL with Coil on top.


View PDF data sheet for specific information.
P5W22 Series, NC, Nylon (PA66) Valves

P5W22 Series - 2/2 N/Closed Direct Lift Diaphragm Solenoid Valves. The Valve Body is made of Nylon (PA66). Standard seals available is NBR, optional seals available is VITON and EPDM. The Operating pressure Range is 0 to Rated MAXIMUM PRESSURE in Datasheet.(Check specific Size and Voltage DC or AC). Suitable for Gravity feed applications(Zero) 0 Bar. Because of the Nylon Body and NBR seal these valves can be used with compatible liquids and gasses. These Valves are Fitted with Large Coils , so please NOTE the POWER CONSUMPTION(see datasheet) and Possible overheating in Direct sunlight. The only further requirement is viscosity below 20 Centistokes. MOUNTING-HORIZONTAL with Coil on top.


View PDF data sheet for specific information.

1/2" Half Inch-15mm BSP Normally Closed, Nylon (PA66) & NBR, See data sheet for pressure range (C14 or C15 coil excl)
PART NO : P5W22NH15S04B
SIZE/DESCRIPTION:
1/2" Half Inch-15mm BSP Normally Closed, Nylon (PA66) & NBR, See data sheet for pressure range (C14 or C15 coil excl)

PRICE FROM: R 553.85 + (Add Coil C14/15 Price)
QUANTITY:


QUANTITY:
PART NO : P5W22NH40S14B
SIZE/DESCRIPTION:
11/2" One and Half inch-40mm BSP Normally Closed, Nylon (PA66) & NBR, See data sheet for pressure range (C41DX coil excl)

PRICE FROM: R 2783.65 + (Add Coil C41 Price)
QUANTITY:


QUANTITY:
PART NO : P5W22NH50S20B
SIZE/DESCRIPTION:
2" Two Inch-50mm BSP Normally Closed, Nylon (PA66) & NBR, See data sheet for pressure range (C41DX coil excl)

PRICE FROM: R 3874.55 + (Add Coil C41 Price)
QUANTITY:


QUANTITY:

P5W23 Series, NO, Nylon (PA66) Valves

P5W23 Series - 2/2 N/Open Direct Lift Diaphragm Solenoid Valves. The Valve Body is made of Nylon (PA66). Standard seals available is NBR, optional seals available is VITON and EPDM. The Operating pressure Range is 0 to Rated Maximum Pressure in Datasheet.(Check specific Size and Voltage DC or AC). Suitable for Gravity feed applications(Zero) 0 Bar. Because of the Nylon Body and NBR seal these valves can be used with compatible liquids and gasses. These Valves are Fitted with Large Coils , so please NOTE the POWER CONSUMPTION(see datasheet) and Possible overheating in Direct sunlight. The only further requirement is viscosity below 20 Centistokes. MOUNTING-HORIZONTAL with Coil on top.


View PDF data sheet for specific information.
P5W23 Series, NO, Nylon (PA66) Valves

P5W23 Series - 2/2 N/Open Direct Lift Diaphragm Solenoid Valves. The Valve Body is made of Nylon (PA66). Standard seals available is NBR, optional seals available is VITON and EPDM. The Operating pressure Range is 0 to Rated Maximum Pressure in Datasheet.(Check specific Size and Voltage DC or AC). Suitable for Gravity feed applications(Zero) 0 Bar. Because of the Nylon Body and NBR seal these valves can be used with compatible liquids and gasses. These Valves are Fitted with Large Coils , so please NOTE the POWER CONSUMPTION(see datasheet) and Possible overheating in Direct sunlight. The only further requirement is viscosity below 20 Centistokes. MOUNTING-HORIZONTAL with Coil on top.


View PDF data sheet for specific information.

1/2" Half Inch-15mm BSP Normally Open, Nylon (PA66) & NBR, See data sheet for pressure range (C14 or C15 coil excl)
PART NO : P5W23NH15S04B
SIZE/DESCRIPTION:
1/2" Half Inch-15mm BSP Normally Open, Nylon (PA66) & NBR, See data sheet for pressure range (C14 or C15 coil excl)

PRICE FROM: R 991.20 + (Add Coil C14/15 Price)
QUANTITY:


QUANTITY:
PART NO : P5W23NH20S06B
SIZE/DESCRIPTION:
3/4" Three Quarter Inch-20mm 22mm BSP Normally Open, Nylon (PA66) & NBR, See data sheet for pressure range (C14 or C15 coil excl)

PRICE FROM: R 1027.15 + (Add Coil C14/15 Price)
QUANTITY:


QUANTITY:
PART NO : P5W23NH25S10B
SIZE/DESCRIPTION:
1" One Inch-25mm BSP Normally Open, Nylon (PA66) & NBR, See data sheet for pressure range (C14 or C15 coil excl)

PRICE FROM: R 1283.20 + (Add Coil C14/15 Price)
QUANTITY:


QUANTITY:
PART NO : P5W23NH40S14B
SIZE/DESCRIPTION:
11/2" One and Half inch-40mm BSP Normally Open, Nylon (PA66) & NBR, See data sheet for pressure range (C41DX coil excl)

PRICE FROM: R 3613.70 + (Add Coil C14/15 Price)
QUANTITY:


QUANTITY:
PART NO : P5W23NH50S20B
SIZE/DESCRIPTION:
2" Two Inch-50mm BSP Normally Open, Nylon (PA66) & NBR, See data sheet for pressure range (C41DX coil excl)

PRICE FROM: R 4095.60 + (Add Coil C14/15 Price)
QUANTITY:


QUANTITY:

P2W22 & PQ22 Series, Stainless Solenoid Valves

P2W22 & PQ22 Series - 2/2 N/Closed Direct Lift Diaphragm Valves. The Valve Body is made of 304 Stainless Steel. Seals available is VITON. The Operating pressure Range is 0 to 6 Bar (DC). WILL WORK FOR GRAVITY FEED Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. The only further requirement is viscosity below 40 Centistokes. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available.


View PDF data sheet for specific information.
P2W22 & PQ22 Series, Stainless Solenoid Valves

P2W22 & PQ22 Series - 2/2 N/Closed Direct Lift Diaphragm Valves. The Valve Body is made of 304 Stainless Steel. Seals available is VITON. The Operating pressure Range is 0 to 6 Bar (DC). WILL WORK FOR GRAVITY FEED Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. The only further requirement is viscosity below 40 Centistokes. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available.


View PDF data sheet for specific information.

1/2" BSP, Stainless Steel & Viton, 0 to 10 Bar (C14/15DX coil excl)
PART NO : P2W22SH15S04
SIZE/DESCRIPTION:
1/2" BSP, Stainless Steel & Viton, 0 to 10 Bar (C14/15DX coil excl)

PRICE FROM: R 1771.55
QUANTITY:


QUANTITY:
PART NO : P2W22SH20S06
SIZE/DESCRIPTION:
3/4" BSP, Stainless Steel & Viton, 0 to 10 Bar (C14/15DX coil excl)

PRICE FROM: R 1992.15
QUANTITY:


QUANTITY:
PART NO : P2W22SH25S10
SIZE/DESCRIPTION:
1" BSP, Stainless Steel & Viton, 0 to 10 Bar (C14/15DX coil excl)

PRICE FROM: R 2460.85
QUANTITY:


QUANTITY:
PART NO : PQ22SH32S12
SIZE/DESCRIPTION:
11/4" BSP, Stainless Steel & Viton, 0 to 10 Bar (AC) 6 Bar (DC) (C16DX coil excl)

PRICE FROM: R 4025.60
QUANTITY:


QUANTITY:
PART NO : PQ22SH40S14
SIZE/DESCRIPTION:
11/2" BSP, Stainless Steel & Viton, 0 to 10 Bar (AC) 6 Bar (DC) (C16DX coil excl)

PRICE FROM: R 4749.35
QUANTITY:


QUANTITY:
PART NO : PQ22SH50S20
SIZE/DESCRIPTION:
2" BSP, Stainless Steel & Viton, 0 to 10 Bar (AC) 6 Bar (DC) (C16DX coil excl)

PRICE FROM: R 6323.75
QUANTITY:


QUANTITY:

PLQS22 Brass Series, Anti Water Hammer & Low Power (NC), Pilot Operated Solenoid Valve

PLQS22 Brass Series, Anti Water Hammer & Low Power (NC), Pilot Operated Solenoid Valve. The Valve Body is made of Brass. Valve Seals are Buna (NBR) natural rubber seals. Maximum 60 Deg C.The Operating pressure Range is 1 to 16 Bar up to 1" and for Larger sizes 12 Bar Maximum. These Valves are Low cost and basic. Their use is for Clean water, Non Corrosive thin Liquids, Compressed Air and Non corrosive gases. (NOT SUITABLE FOR GRAVITY FEED APPLICATIONS) SPECIAL PRICE DISCOUNTS ONLY APPLY WHILE STOCK LASTS. The New Replacements Range is PLQM22.


View PDF data sheet for specific information.
PLQS22 Brass Series, Anti Water Hammer & Low Power (NC), Pilot Operated Solenoid Valve

PLQS22 Brass Series, Anti Water Hammer & Low Power (NC), Pilot Operated Solenoid Valve. The Valve Body is made of Brass. Valve Seals are Buna (NBR) natural rubber seals. Maximum 60 Deg C.The Operating pressure Range is 1 to 16 Bar up to 1" and for Larger sizes 12 Bar Maximum. These Valves are Low cost and basic. Their use is for Clean water, Non Corrosive thin Liquids, Compressed Air and Non corrosive gases. (NOT SUITABLE FOR GRAVITY FEED APPLICATIONS) SPECIAL PRICE DISCOUNTS ONLY APPLY WHILE STOCK LASTS. The New Replacements Range is PLQM22.


View PDF data sheet for specific information.

3/4" BSP Normally Closed Brass & NBR, 1 to 16 Bar (C1010 coil excl)
PART NO : PLQS22BH20S06
SIZE/DESCRIPTION:
3/4" BSP Normally Closed Brass & NBR, 1 to 16 Bar (C1010 coil excl)

PRICE FROM: R 455.00 + (ADD COIL PRICE Below) LAST STOCK
QUANTITY:


QUANTITY:

PLQM22 Brass Series, Anti Water Hammer & Low Power (NC), Pilot Operated Solenoid Valve

PLQM22 Brass Series, Anti Water Hammer & Low Power (NC), Pilot Operated Solenoid Valve. The Valve Body is made of Brass. Valve Seals are VITON. The Operating pressure Range is 0,3 to 16 Bar for AC voltages and 10 Bar for DC voltages. These Valves are Low cost and basic. Their use is for Clean water, Non Corrosive thin Liquids, Compressed Air and Non corrosive gases. (NOT SUITABLE FOR GRAVITY FEED APPLICATIONS)


View PDF data sheet for specific information.
PLQM22 Brass Series, Anti Water Hammer & Low Power (NC), Pilot Operated Solenoid Valve

PLQM22 Brass Series, Anti Water Hammer & Low Power (NC), Pilot Operated Solenoid Valve. The Valve Body is made of Brass. Valve Seals are VITON. The Operating pressure Range is 0,3 to 16 Bar for AC voltages and 10 Bar for DC voltages. These Valves are Low cost and basic. Their use is for Clean water, Non Corrosive thin Liquids, Compressed Air and Non corrosive gases. (NOT SUITABLE FOR GRAVITY FEED APPLICATIONS)


View PDF data sheet for specific information.

1/2" BSP Normally Closed Brass & Viton, 0,3 to 16 Bar (AC) 10 Bar (DC) (C1010 coil excl)
PART NO : PLQM22BH15S04
SIZE/DESCRIPTION:
1/2" BSP Normally Closed Brass & Viton, 0,3 to 16 Bar (AC) 10 Bar (DC) (C1010 coil excl)

PRICE FROM: R 1081.60
QUANTITY:


QUANTITY:
PART NO : PLQM22BH20S06
SIZE/DESCRIPTION:
3/4" BSP Normally Closed Brass & Viton, 0,3 to 16 Bar (AC) 10 Bar (DC) (C1010 coil excl)

PRICE FROM: R 1261.45
QUANTITY:


QUANTITY:
PART NO : PLQM22BH25S10
SIZE/DESCRIPTION:
1" BSP Normally Closed Brass & Viton, 0,3 to 16 Bar (AC) 10 Bar (DC) (C1010 coil excl)

PRICE FROM: R 2026.60
QUANTITY:


QUANTITY:

© PNEUMATRON 2024
