TIMER DRAIN VALVE



CONTACT: Call,WhatsApp or EMail: Markus & Bianca
Tel:(012) 661 8874 - Cell:061 444 2242 - Cell:082 904 2225
EMail: sales01@pneumatron.co.za OR valve2225@gmail.com


Compressed Air systems accumulate a large amount of condensate or water due to the Compression of Air by the Compressor. This condensate and water can be a cause of many Solenoid Valve and Equipment Malfunctions.

Automatic Electric Timer Drain Valves fitted at specific Locations in an Compressed Air Line or on a Compressor Tank will drain condensate on a set time interval automatically. This will reduce maintenance and manual draining of condensate or water.

Automatic Electric Timer Solenoid drain valves work cyclicly.(ON and OFF Timer -see Below).

You can set the Electric timer on the Valve to open the valve for ON-PERIOD(Adjustable 0,5-10 seconds),then thereafter follows the OFF PERIOD Adjustable 0,5 to 45 Minutes. The cycle will repeat continuously/repeatedly or cyclicly. So for example: You could drain the tank every 20Minutes(OFF PERIOD) for  5 seconds (ON PERIOD).

The Electric Timer unit is fitted on the Valve - Both the ON and OFF times has buttons for adjustment of the times by yourself. Turn buttons for TEC-11/TEC-22 and Program Push buttons for TEC-99.

TEC-11 & TEC-22(Combo D-Lux Integrated Strainer Drain Valves)

1/2" TEC-11 & TEC-22-Series - 2/2 N/Closed Turn Knob Electronic Timer Controlled Direct Combo D-Lux Integrated Strainer Drain Valve. The Valve Body is made of Brass The Operating pressure Range is 0 to 16 Bar. With TEC-11 & TEC-22 Timer Module - You can set the timer to open the valve for ON-PERIOD(Adjustable 0,5-10 seconds), after the OFF PERIOD(Adjustable 0,5 to 45 Minutes. The cycle will repeat continuously/repeatedly. So for example: You could drain the tank every 20 Minutes (OFF PERIOD) for 5 seconds (ON PERIOD). With TEC-99 Digital Timer Module fitted you have 4 x Digital membrane push buttons. To adjust the ON Time (valve coil ON) between 1 Second to 99 Hours, 59 Minutes and 59 Hours AND to adjust OFF time (Interval before it Switches ON again)between 1 Second to 99 Hours, 59 Minutes and 59 Hours.


View PDF data sheet for specific information.
TEC-11 & TEC-22(Combo D-Lux Integrated Strainer Drain Valves)

1/2" TEC-11 & TEC-22-Series - 2/2 N/Closed Turn Knob Electronic Timer Controlled Direct Combo D-Lux Integrated Strainer Drain Valve. The Valve Body is made of Brass The Operating pressure Range is 0 to 16 Bar. With TEC-11 & TEC-22 Timer Module - You can set the timer to open the valve for ON-PERIOD(Adjustable 0,5-10 seconds), after the OFF PERIOD(Adjustable 0,5 to 45 Minutes. The cycle will repeat continuously/repeatedly. So for example: You could drain the tank every 20 Minutes (OFF PERIOD) for 5 seconds (ON PERIOD). With TEC-99 Digital Timer Module fitted you have 4 x Digital membrane push buttons. To adjust the ON Time (valve coil ON) between 1 Second to 99 Hours, 59 Minutes and 59 Hours AND to adjust OFF time (Interval before it Switches ON again)between 1 Second to 99 Hours, 59 Minutes and 59 Hours.


View PDF data sheet for specific information.

1/2" Sol V, 2/2 N/C,Brass Body,Viton,Orf 4mm,0-10Bar-ON:0,5-10 Seconds,OFF: 0,5 to 45Min
PART NO : TEC-11 (Combo D-Lux Integrated Strainer Drain Valves with analog timer)
SIZE/DESCRIPTION:
1/2" Sol V, 2/2 N/C,Brass Body,Viton,Orf 4mm,0-10Bar-ON:0,5-10 Seconds,OFF: 0,5 to 45Min

PRICE FROM: R 864.00
QUANTITY:


QUANTITY:

TECH-11,TECH-22 and TECH-99 Din Plug Timer Module

TECH-11,TECH-22 and TECH-99 Din Plug Timer Modules - Fits as a timer unit between a Coil Din Plug and the Coil(Can be retrofitted on Normal Valves). This allows adjustable ON and OFF Timing of the valve on the valve itself without additional adjustments. TECH-11 & TECH-22 Electronic Timer Module with 2 x Analog turn Knobs to adjust the ON Time (valve coil ON) between 0.5 and 10 Seconds and 2nd Knob to adjust OFF time (Interval before it Switches ON again)between 0.5 and 45 Minutes. The cycle will repeat continuously/repeatedly. So for example: You could drain the tank every 20 Minutes (OFF PERIOD) for 5 seconds (ON PERIOD). TECH-99 Digital Electronic Timer Module with 4 x Digital membrane push buttons. To adjust the ON Time (valve coil ON) between 1 Second to 99 Hours, 59 Minutes and 59 Hours AND to adjust OFF time (Interval before it Switches ON again)between 1 Second to 99 Hours, 59 Minutes and 59 Hours. Could also be used as Shower Timer with 3/5 or more minutes ON and OFF 99 Hours. So when connected to Light switch will open Shower or Bath Fill Water for set minutes and then switch off. Will only work again when Light is switched ON again. This can limit shower times to conserve Water. No additional wiring, Just 2 wires to Coil of Valve(ALL DONE)


View PDF data sheet for specific information.
TECH-11,TECH-22 and TECH-99 Din Plug Timer Module

TECH-11,TECH-22 and TECH-99 Din Plug Timer Modules - Fits as a timer unit between a Coil Din Plug and the Coil(Can be retrofitted on Normal Valves). This allows adjustable ON and OFF Timing of the valve on the valve itself without additional adjustments. TECH-11 & TECH-22 Electronic Timer Module with 2 x Analog turn Knobs to adjust the ON Time (valve coil ON) between 0.5 and 10 Seconds and 2nd Knob to adjust OFF time (Interval before it Switches ON again)between 0.5 and 45 Minutes. The cycle will repeat continuously/repeatedly. So for example: You could drain the tank every 20 Minutes (OFF PERIOD) for 5 seconds (ON PERIOD). TECH-99 Digital Electronic Timer Module with 4 x Digital membrane push buttons. To adjust the ON Time (valve coil ON) between 1 Second to 99 Hours, 59 Minutes and 59 Hours AND to adjust OFF time (Interval before it Switches ON again)between 1 Second to 99 Hours, 59 Minutes and 59 Hours. Could also be used as Shower Timer with 3/5 or more minutes ON and OFF 99 Hours. So when connected to Light switch will open Shower or Bath Fill Water for set minutes and then switch off. Will only work again when Light is switched ON again. This can limit shower times to conserve Water. No additional wiring, Just 2 wires to Coil of Valve(ALL DONE)


View PDF data sheet for specific information.

Digital Din Plug Timer: ON adjustable: 0000 to 99 Hours, 59 minutes, 59 Seconds - OFF : Same as ON
PART NO : TECH-99 Digital Timer Module (Only)
SIZE/DESCRIPTION:
Digital Din Plug Timer: ON adjustable: 0000 to 99 Hours, 59 minutes, 59 Seconds - OFF : Same as ON

PRICE FROM: R 744.00
QUANTITY:


QUANTITY:
PART NO : TECH-11 Analog Timer Module (Only)
SIZE/DESCRIPTION:
Analog Din Plug Timer: ON adjustable: 0-10 Sec, OFF: 0.5 to 45 Minutes

PRICE FROM: R 530.40
QUANTITY:


QUANTITY:

PVTX2XX Stainless Steel Series Electric Timer Ball Valves

PVTX2XX Stainless Steel Series ,2/2 Way Stainless Steel FULL BORE Electric Timer Ball Valves. These Valves have switches that switch them off when they reach end of rotation. Stays open for selected time then closes for selected time. Features: Motor Enclosure:IP65 Body Material Stainless Steel Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 90 Degrees C. Voltages: 3,5,9,12,15,24VDC and 110/220VAC(See Specific Stock Item) Applications: It is used for industrial line shutoff, home water, solar water heaters and small automatic control equipment.


View PDF data sheet for specific information.
PVTX2XX Stainless Steel Series Electric Timer Ball Valves

PVTX2XX Stainless Steel Series ,2/2 Way Stainless Steel FULL BORE Electric Timer Ball Valves. These Valves have switches that switch them off when they reach end of rotation. Stays open for selected time then closes for selected time. Features: Motor Enclosure:IP65 Body Material Stainless Steel Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 90 Degrees C. Voltages: 3,5,9,12,15,24VDC and 110/220VAC(See Specific Stock Item) Applications: It is used for industrial line shutoff, home water, solar water heaters and small automatic control equipment.


View PDF data sheet for specific information.

1/2" FULL BORE BSP. 2/2 Motorised Stainless Steel Timer Ball Valve-XXX-VAC/DC. IP65, With Position Indicator.
PART NO : PVTX215W22DX
SIZE/DESCRIPTION:
1/2" FULL BORE BSP. 2/2 Motorised Stainless Steel Timer Ball Valve-XXX-VAC/DC. IP65, With Position Indicator.

PRICE FROM: R 2450.00
QUANTITY:


QUANTITY:

PBVX232 Brass Ball Valve Series with Feedback or Timer

PBVX232 Brass Ball Valve Series with W52 Feedback Signal Actuator or Timer Actuator. These Valves have switches that switch them off when they reach end of rotation. The Dc Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP65 Body Material Brass Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages:AC/DC9-24V and AC110-220V(See Specific Stock Item) Applications: It is used for Industrial Line Shutoff,home water, Solar water heaters and small automatic control equipment.


View PDF data sheet for specific information.
PBVX232 Brass Ball Valve Series with Feedback or Timer

PBVX232 Brass Ball Valve Series with W52 Feedback Signal Actuator or Timer Actuator. These Valves have switches that switch them off when they reach end of rotation. The Dc Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP65 Body Material Brass Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages:AC/DC9-24V and AC110-220V(See Specific Stock Item) Applications: It is used for Industrial Line Shutoff,home water, Solar water heaters and small automatic control equipment.


View PDF data sheet for specific information.

11/4"(32mm) FULL BORE BSP. 2/2 Motorised Brass Ball Valve- W52 Actuator XXX-VAC/DC. IP65, Position Indicator
PART NO : PBVX232W52DX
SIZE/DESCRIPTION:
11/4"(32mm) FULL BORE BSP. 2/2 Motorised Brass Ball Valve- W52 Actuator XXX-VAC/DC. IP65, Position Indicator

PRICE FROM: R 2980.00(Min 2 Items Ordered)
QUANTITY:


QUANTITY:
PART NO : PBVT232W22DX
SIZE/DESCRIPTION:
11/4"(32mm) FULL BORE BSP. 2/2 Motorised Brass Ball Valve- W22 Timer Actuator XXX-VAC/DC. IP65, Position Indicator

PRICE FROM: R 3500.00(Min 2 Items Ordered)
QUANTITY:


QUANTITY:

© PNEUMATRON 2019
