In South Africa there a specific machine builders and factories that will only use PNEMATRON brand Solenoid Valves.

HELP ME! Choose the subject below you need help with.

Click it and you will go to an answer.

1) About Solenoid Valves?
2) How to select a Valve?
3) How to use ENQUIRY CART?
4) Fluid Compatability Chart?
5) Download Valve Enquiry Sheet?

Solenoid valves for steam is used in boiler and heating systems and require valves with PTFE seals (Rated up to 180 Deg C) and Solid Servo Metal Pistons instead of rubber daiphrams, that have a limited Temperature Resistance - usually only up to 150 deg C. The Steam Valves below are designed for these high temperatures.

The PLA22/3 Stainless Steel Solenoid Valve (Below) can also be used for HOT or/and CORROSIVE gasses and Liquids. For lower temperature applications these valves can be used up to a maximum pressure of 40 Bar.(Maximum differential pressure -Delta-P=25Bar)

PSP22 Series, N/Closed, STEAM Stainless Solenoid Valves

PSP22 Series, N/Closed, STEAM Solenoid Valves. The Valve Body is made of 304 Stainless Steel. Seals are PTFE. The Operating pressure Range is 0,5 to 16 Bar. Temperature up to 180 Deg Celsius.(Valve coil needs proper ventilation and can only be energized for up to 4 hours-combined in 24 hour cycle ) The Specialized Piston Design has PTFE Embedded Ring seals. The guide rings on the piston Isolates the heat from the Coil and limits steam contact with the Valve Body.


View PDF data sheet for specific information.
PSP22 Series, N/Closed, STEAM Stainless Solenoid Valves

PSP22 Series, N/Closed, STEAM Solenoid Valves. The Valve Body is made of 304 Stainless Steel. Seals are PTFE. The Operating pressure Range is 0,5 to 16 Bar. Temperature up to 180 Deg Celsius.(Valve coil needs proper ventilation and can only be energized for up to 4 hours-combined in 24 hour cycle ) The Specialized Piston Design has PTFE Embedded Ring seals. The guide rings on the piston Isolates the heat from the Coil and limits steam contact with the Valve Body.


View PDF data sheet for specific information.

STM 1/4" Sol Valve,2/2 N/Clsd Stainless Steel 316 Body,PTFE ,Orf 3mm,0-16 Bar, 180 Deg cSTM 1/4" Sol Valve,2/2 N/Clsd S/S 316 Body,PTFE ,Orf 3mm,0-16 Bar, 180 Deg C (C19DX coil excl)
PART NO : PSTM22SH03S02PT
SIZE/DESCRIPTION:
STM 1/4" Sol Valve,2/2 N/Clsd Stainless Steel 316 Body,PTFE ,Orf 3mm,0-16 Bar, 180 Deg C (C19DX coil excl)

PRICE FROM: R 1028.00
QUANTITY:


QUANTITY:
PART NO : PSP22SH15S04PT
SIZE/DESCRIPTION:
1/2" BSP, Stainless Steel 304 & PTFE Piston, 0,5 to 16 Bar, 180 Deg Celsius. (C12DXH coil excl)

PRICE FROM: R 896.00
QUANTITY:


QUANTITY:
PART NO : PSP22SH50S20PT
SIZE/DESCRIPTION:
2" BSP, Stainless Steel 304 & PTFE Piston, 0,5 to 16 Bar, 180 Deg Celsius. (C12DXH coil excl)

PRICE FROM: R 2516.00
QUANTITY:


QUANTITY:

PLA22 Series, N/Closed, STEAM Stainless Solenoid Valves

PLA22 Series, N/Closed, STEAM Stainless Solenoid Valves. The Valve Body is made of 304 Stainless Steel. Seals are PTFE. The Body Working Maximum Pressure is 40 Bar. The Operating Differential pressure Range is 0,5 to 10 Bar (STEAM). The Differential Pressure for Other media is 0-5 to 25 Bar (AC Coils) and 0.5 to 20 Bar (DC Coils). Temperature up to 180 Deg Celsius.(Valve coil needs proper ventilation) The Specialized Piston Design has PTFE Embedded Ring seals. The guide rings on the piston Isolates the heat from the Coil and limits steam contact with the Valve Body.


View PDF data sheet for specific information.
PLA22 Series, N/Closed, STEAM Stainless Solenoid Valves

PLA22 Series, N/Closed, STEAM Stainless Solenoid Valves. The Valve Body is made of 304 Stainless Steel. Seals are PTFE. The Body Working Maximum Pressure is 40 Bar. The Operating Differential pressure Range is 0,5 to 10 Bar (STEAM). The Differential Pressure for Other media is 0-5 to 25 Bar (AC Coils) and 0.5 to 20 Bar (DC Coils). Temperature up to 180 Deg Celsius.(Valve coil needs proper ventilation) The Specialized Piston Design has PTFE Embedded Ring seals. The guide rings on the piston Isolates the heat from the Coil and limits steam contact with the Valve Body.


View PDF data sheet for specific information.

1/2" BSP, Stainless Steel 304 & PTFE Piston, 0,5 to 10/20/25 Bar, 180 Deg Celsius. (CAW14 or C14 coil excl)
PART NO : PLA22SH15S04PT
SIZE/DESCRIPTION:
1/2" BSP, Stainless Steel 304 & PTFE Piston, 0,5 to 10/20/25 Bar, 180 Deg Celsius. (CAW14 or C14 coil excl)

PRICE FROM: R 1920.00
QUANTITY:


QUANTITY:
PART NO : PLA22SH20S06PT
SIZE/DESCRIPTION:
3/4" BSP, Stainless Steel 304 & PTFE Piston, 0,5 to 10/20/25 Bar, 180 Deg Celsius. (CAW14 or C14 coil excl)

PRICE FROM: R 2180.00
QUANTITY:


QUANTITY:
PART NO : PLA22SH25S10PT
SIZE/DESCRIPTION:
1" BSP, Stainless Steel 304 & PTFE Piston, 0,5 to 10/20/25 Bar, 180 Deg Celsius. (CAW14 or C14 coil excl)

PRICE FROM: R 2588.00
QUANTITY:


QUANTITY:
PART NO : PLA22SH40S14PT
SIZE/DESCRIPTION:
11/2" BSP, Stainless Steel 304 & PTFE Piston, 0,5 to 10/20/25 Bar, 180 Deg Celsius. (CAW14 or C14 coil excl)

PRICE FROM: R 4471.00
QUANTITY:


QUANTITY:
PART NO : PLA22SH50S20PT
SIZE/DESCRIPTION:
2" BSP, Stainless Steel 304 & PTFE Piston, 0,5 to 10/20/25 Bar, 180 Deg Celsius. (CAW14 or C14 coil excl)

PRICE FROM: R 5920.00
QUANTITY:


QUANTITY:

PLA23 Series, N/OPEN, STEAM Stainless Solenoid Valves

PLA23 Series, N/OPEN, STEAM Stainless Solenoid Valves The Valve Body is made of 304 Stainless Steel. Seals are PTFE. The Operating pressure Range is 0,5 to 10 Bar (STEAM). Temperature up to 180 Deg Celsius.(Valve coil needs proper ventilation) The Specialized Piston Design has PTFE Embedded Ring seals. The guide rings on the piston Isolates the heat from the Coil and limits steam contact with the Valve Body.


View PDF data sheet for specific information.
PLA23 Series, N/OPEN, STEAM Stainless Solenoid Valves

PLA23 Series, N/OPEN, STEAM Stainless Solenoid Valves The Valve Body is made of 304 Stainless Steel. Seals are PTFE. The Operating pressure Range is 0,5 to 10 Bar (STEAM). Temperature up to 180 Deg Celsius.(Valve coil needs proper ventilation) The Specialized Piston Design has PTFE Embedded Ring seals. The guide rings on the piston Isolates the heat from the Coil and limits steam contact with the Valve Body.


View PDF data sheet for specific information.

1/2" BSP, Normally Open Stainless Steel 304 & PTFE Piston, 0,5 to 10 Bar (Steam), 180 Deg Celsius. (CAW14 or C14 coil excl)
PART NO : PLA23SH15S04PT
SIZE/DESCRIPTION:
1/2" BSP, Normally Open Stainless Steel 304 & PTFE Piston, 0,5 to 10 Bar (Steam), 180 Deg Celsius. (CAW14 or C14 coil excl)

PRICE FROM: R 2640.00
QUANTITY:


QUANTITY:
PART NO : PLA23SH20S06PT
SIZE/DESCRIPTION:
3/4" BSP, Normally Open Stainless Steel 304 & PTFE Piston, 0,5 to 10 Bar (Steam), 180 Deg Celsius. (CAW14 or C14 coil excl)

PRICE FROM: R 2890.00
QUANTITY:


QUANTITY:
PART NO : PLA23SH25S10PT
SIZE/DESCRIPTION:
1" BSP, Normally Open Stainless Steel 304 & PTFE Piston, 0,5 to 10 Bar (Steam), 180 Deg Celsius. (CAW14 or C14 coil excl)

PRICE FROM: R 3262.00
QUANTITY:


QUANTITY:
PART NO : PLA23SH40S14PT
SIZE/DESCRIPTION:
11/2" BSP, Normally Open Stainless Steel 304 & PTFE Piston, 0,5 to 10 Bar (Steam), 180 Deg Celsius. (CAW14 or C14 coil excl)

PRICE FROM: R 4790.00
QUANTITY:


QUANTITY:
PART NO : PLA23SH50S20PT
SIZE/DESCRIPTION:
2" BSP, Normally Open Stainless Steel 304 & PTFE Piston, 0,5 to 10 Bar (Steam), 180 Deg Celsius. (CAW14 or C14 coil excl)

PRICE FROM: R 6035.00
QUANTITY:


QUANTITY:

PNEUMATRON STEAM VALVE COILS/SOLENOIDS

220VAC Solenoid,24VDC Solenoid,12VDC Solenoid,110VAC Solenoid & 380VAC Solenoid. C12DXH Series - HIGH TEMPERATURE SOLENOID COIL used on Solenoid Valve Types PSP22 CAW14DX Series - HIGH TEMPERATURE SOLENOID COIL used for solenoid valve types PLA22 & PLA23 C14DX Series - Standard F-Type coil, mostly AC voltages, to be used on PLA22 & PLA23 for standard applications. C15DX Series - Standard F-Type coil, mostly DC voltages, to be used on PLA22 & PLA23 for standard applications.

PNEUMATRON STEAM VALVE COILS/SOLENOIDS

220VAC Solenoid,24VDC Solenoid,12VDC Solenoid,110VAC Solenoid & 380VAC Solenoid. C12DXH Series - HIGH TEMPERATURE SOLENOID COIL used on Solenoid Valve Types PSP22 CAW14DX Series - HIGH TEMPERATURE SOLENOID COIL used for solenoid valve types PLA22 & PLA23 C14DX Series - Standard F-Type coil, mostly AC voltages, to be used on PLA22 & PLA23 for standard applications. C15DX Series - Standard F-Type coil, mostly DC voltages, to be used on PLA22 & PLA23 for standard applications.


C12D HIGH TEMP Coil & Plug for PD22 Valves.XXX-Specifies Voltage.
PART NO : C12DXH-XXX
SIZE/DESCRIPTION:
1/2" to 2" PSP22 Valves.(XXX Indicates Voltage)

PRICE FROM: R 532-00
QUANTITY:


QUANTITY:
PART NO : CAW14-XXX
SIZE/DESCRIPTION:
Coil & Plug for 1/2" to 2" PLA STEAM Valves.(XXX Indicates Voltage)

PRICE FROM: R 382.00
QUANTITY:


QUANTITY:
PART NO : C14DX-XXX
SIZE/DESCRIPTION:
C14 Coil & Plug for P5W(Small), P2W(Small),P3W23, PLP23, PLA(Standard) & PLG XXX-Specifies Voltage.

PRICE FROM: R 335-00
QUANTITY:


QUANTITY:
PART NO : C15DX-XXX
SIZE/DESCRIPTION:
C15 Coil & Plug for P5W (small), P2W (small), P3W23, PLP23 & PLA Standard Valves.XXX-Specifies Voltage.

PRICE FROM: R 386-00
QUANTITY:


QUANTITY:
