Electric Proportional Controlled Ball Valves are used in applications where the media flow is controlled by proportion, hence the name proportionally controlled.

PVP2XX Series Proportional Electric Ball Valves

PVP2XX Series, 2/2 Way Stainless Steel FULL BORE Proportional Electric Ball Valves. These Valves open proportionally as the control signal increases from 4mA (Closed) to Fully open at (20mA). The DC Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP65 Body Material Stainless Steel 304 PTFE Ball seals and FKM(viton) stem seals Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages: DC15-24V Control signal: 4-20mA Standard(Optional Import 0-5V or 0-10V).


View PDF data sheet for specific information.
PVP2XX Series Proportional Electric Ball Valves

PVP2XX Series, 2/2 Way Stainless Steel FULL BORE Proportional Electric Ball Valves. These Valves open proportionally as the control signal increases from 4mA (Closed) to Fully open at (20mA). The DC Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP65 Body Material Stainless Steel 304 PTFE Ball seals and FKM(viton) stem seals Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages: DC15-24V Control signal: 4-20mA Standard(Optional Import 0-5V or 0-10V).


View PDF data sheet for specific information.

1/4" Proportional Control , 2 Way, S/Steel Ball Valve, Supply 24VDC Input, Control 4-20mA
PART NO : PVP208-420
SIZE/DESCRIPTION:
1/4" Proportional Control , 2 Way, S/Steel Ball Valve, Supply 24VDC Input, Control 4-20mA

PRICE FROM: R 7177.45
QUANTITY:


QUANTITY:
PART NO : PVP210-420
SIZE/DESCRIPTION:
3/8" Proportional Control , 2 Way, S/Steel Ball Valve, Supply 24VDC Input, Control 4-20mA

PRICE FROM: R 7464.55
QUANTITY:


QUANTITY:
PART NO : PVP215-420
SIZE/DESCRIPTION:
1/2" Proportional Control , 2 Way, S/Steel Ball Valve, Supply 24VDC Input, Control 4-20mA

PRICE FROM: R 8030.30
QUANTITY:


QUANTITY:
PART NO : PVP220-420
SIZE/DESCRIPTION:
3/4" Proportional Control, 2 Way, S/Steel Ball Valve, Supply 24VDC Input, Control 4-20mA

PRICE FROM: R 8173.85
QUANTITY:


QUANTITY:
PART NO : PVP225-420
SIZE/DESCRIPTION:
1" Proportional Control , 2 Way, S/Steel Ball Valve, Supply 24VDC Input, Control 4-20mA

PRICE FROM: R 8866.25
QUANTITY:


QUANTITY:

PPRVS-X2XX Brass Series Proportional Electric Ball Valves

PPRVS-X2XX Brass Series, 2/2 Way or 3/2 Way Brass Proportional Electric Ball Valves. These Valves open proportionally as the control signal increases from 4mA (Closed) to Fully open at (20mA). The DC Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP65 Body Material Brass PTFE Ball seals and EPDM stem seals Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 90 Degrees C. Supply Voltage: 24VDC Control signal: 4-20mA Standard or 2-10VDC


View PDF data sheet for specific information.
PPRVS-X2XX Brass Series Proportional Electric Ball Valves

PPRVS-X2XX Brass Series, 2/2 Way or 3/2 Way Brass Proportional Electric Ball Valves. These Valves open proportionally as the control signal increases from 4mA (Closed) to Fully open at (20mA). The DC Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP65 Body Material Brass PTFE Ball seals and EPDM stem seals Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 90 Degrees C. Supply Voltage: 24VDC Control signal: 4-20mA Standard or 2-10VDC


View PDF data sheet for specific information.

11/2" 2 Way Proportional Control, Brass Ball Valve, Supply 24VDC Input, Control 4-20mA
PART NO : PPRVS2240-420
SIZE/DESCRIPTION:
11/2" 2 Way Proportional Control, Brass Ball Valve, Supply 24VDC Input, Control 4-20mA

PRICE FROM: R 9806.25
QUANTITY:


QUANTITY:
PART NO : PPRVS2250-420
SIZE/DESCRIPTION:
2" 2 Way Proportional Control, Brass Ball Valve, Supply 24VDC Input, Control 4-20mA

PRICE FROM: R 13456.15
QUANTITY:


QUANTITY:
PART NO : PPRVS3215-420
SIZE/DESCRIPTION:
1/2" 3 Way Proportional Control, Brass Ball Valve, Supply 24VDC Input, Control 4-20mA

PRICE FROM: R 10800.00
QUANTITY:


QUANTITY:
PART NO : PPRVS3220-420
SIZE/DESCRIPTION:
3/4" 3 Way Proportional Control, Brass Ball Valve, Supply 24VDC Input, Control 4-20mA

PRICE FROM: R 11100.00
QUANTITY:


QUANTITY:
PART NO : PPRVS3225-420
SIZE/DESCRIPTION:
1" 3 Way Proportional Control, Brass Ball Valve, Supply 24VDC Input, Control 4-20mA

PRICE FROM: R 11500.00
QUANTITY:


QUANTITY:
PART NO : PPRVS3232-420
SIZE/DESCRIPTION:
11/4" 3 Way Proportional Control, Brass Ball Valve, Supply 24VDC Input, Control 4-20mA

PRICE FROM: R 13620.00
QUANTITY:


QUANTITY:
PART NO : PPRVS3240-420
SIZE/DESCRIPTION:
11/2" 3 Way Proportional Control, Brass Ball Valve, Supply 24VDC Input, Control 4-20mA

PRICE FROM: R 17180.40
QUANTITY:


QUANTITY:
PART NO : PPRVS3250-420
SIZE/DESCRIPTION:
2" 3 Way Proportional Control, Brass Ball Valve, Supply 24VDC Input, Control 4-20mA

PRICE FROM: R 18180.40
QUANTITY:


QUANTITY:

PVPA2XX Series Proportional Electric Ball Valves

PVP2XX Series, 2/2 Way Stainless Steel FULL BORE Proportional Electric Ball Valves. These Valves open proportionally as the control signal increases from 4mA (Closed) to Fully open at (20mA). The DC Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP65 Body Material Stainless Steel 304 PTFE Ball seals and FKM(viton) stem seals Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages: DC12-24V Control signal: 4-20mA Standard.


View PDF data sheet for specific information.
PVPA2XX Series Proportional Electric Ball Valves

PVP2XX Series, 2/2 Way Stainless Steel FULL BORE Proportional Electric Ball Valves. These Valves open proportionally as the control signal increases from 4mA (Closed) to Fully open at (20mA). The DC Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP65 Body Material Stainless Steel 304 PTFE Ball seals and FKM(viton) stem seals Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages: DC12-24V Control signal: 4-20mA Standard.


View PDF data sheet for specific information.

11/2" Proportional Control , 2 Way, S/Steel Ball Valve, Supply 24VDC Input, Control 4-20mA
PART NO : PVPA240-420-420
SIZE/DESCRIPTION:
11/2" Proportional Control , 2 Way, S/Steel Ball Valve, Supply 24VDC Input, Control 4-20mA

PRICE FROM: R 13038.15
QUANTITY:


QUANTITY:
PART NO : PVPA250-420-420
SIZE/DESCRIPTION:
2" Proportional Control , 2 Way, S/Steel Ball Valve, Supply 24VDC Input, Control 4-20mA

PRICE FROM: R 13816.20
QUANTITY:


QUANTITY:
