PDS22 Series - 2/2 N/Closed Pilot Operated, High Pressure Solenoid Valves. The Valve Body is made of Heavy Gauge Brass or 316 Stainless Steel. Seals are VITON. The Operating pressure Range is 0,3 to 16 Bar & up to 140 Deg C (NOT FOR STEAM)
| PDS22BH Series, N/Closed, Pilot Operated, High Pressure Brass Solenoid Valves | |
 |
PDS22BH Series - 2/2 N/Closed Pilot Operated, High Pressure Solenoid Valves. The Valve Body is made of Brass. Seals available is VITON. The Operating pressure Range is 0,3 to 16 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses which is compatible with Brass and Viton. The only further requirement is viscosity below 40 Centistokes and a Minimum available pressure of 0,3 Bar(3 Meter Head). Thus not suitable for Gravity feed applications. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available.  View PDF data sheet for specific information.
|
| PDS22BH Series, N/Closed, Pilot Operated, High Pressure Brass Solenoid Valves | |
|
|
|
PDS22BH Series - 2/2 N/Closed Pilot Operated, High Pressure Solenoid Valves. The Valve Body is made of Brass. Seals available is VITON. The Operating pressure Range is 0,3 to 16 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses which is compatible with Brass and Viton. The only further requirement is viscosity below 40 Centistokes and a Minimum available pressure of 0,3 Bar(3 Meter Head). Thus not suitable for Gravity feed applications. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available. View PDF data sheet for specific information.
|
|
| 1/2" BSP Brass & VITON, Normally Closed, 0,5 to 16 Bar (C13 coil excl) | |||||||
| PART NO : PDS22BH15S04 SIZE/DESCRIPTION: 1/2" BSP Brass & VITON, Normally Closed, 0,5 to 16 Bar (C13 coil excl) PRICE FROM: R 1640.60 |
|
||||||
| PART NO : PDS22BH20S06 SIZE/DESCRIPTION: 3/4" BSP, Brass & VITON, Normally Closed, 0,5 to 16 Bar (C13 coil excl) PRICE FROM: R 1861.15 |
|
||||||
| PART NO : PDS22BH25S10 SIZE/DESCRIPTION: 1" BSP, Brass & VITON, Normally Closed, 0,5 to 16 Bar (C13 coil excl) PRICE FROM: R 2357.45 |
|
||||||
| PART NO : PDS22BH32S12 SIZE/DESCRIPTION: 11/4" BSP, Brass & VITON, Normally Closed, 0,5 to 16 Bar (C13 coil excl) PRICE FROM: R 3592.70 |
|
||||||
| PART NO : PDS22BH40S14 SIZE/DESCRIPTION: 11/2" BSP, Brass & VITON, Normally Closed, 0,5 to 16 Bar (C13 coil excl) PRICE FROM: R 4117.95 |
|
||||||
| PART NO : PDS22BH50S20 SIZE/DESCRIPTION: 2" BSP, Brass & VITON, Normally Closed, 0,5 to 16 Bar (C13 coil excl) PRICE FROM: R 6104.55 |
|
||||||
| PDS22SH Series, N/Closed, Pilot Operated, High Pressure SS316 Solenoid Valves | |
 |
PDS22 Series - 2/2 N/Closed Pilot Operated, High Pressure Solenoid Valves. The Valve Body is made of 316 Stainless Steel. Seals available is NBR, VITON and EPDM. The Operating pressure Range is 0,3 to 16 Bar. The Valve Body is made of 316 Stainless Steel. Seals standard is VITON with NBR and EPDM available on order. The Operating pressure Range is 0,3 to 16 Bar. Because of the Body Material and Viton seals these valves can be used in with different Liquids and gasses with 99% compatibility. These solenoid valves a good for drinking, potable, medical grade and food grade water or other liquids. The only further requirement is viscosity below 40 Centistokes and a Minimum available pressure of 0,3 Bar (3 Meter Head). Not suitable for Gravity feed applications. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available. View PDF data sheet for specific information.
|
| PDS22SH Series, N/Closed, Pilot Operated, High Pressure SS316 Solenoid Valves | |
|
|
|
PDS22 Series - 2/2 N/Closed Pilot Operated, High Pressure Solenoid Valves. The Valve Body is made of 316 Stainless Steel. Seals available is NBR, VITON and EPDM. The Operating pressure Range is 0,3 to 16 Bar. The Valve Body is made of 316 Stainless Steel. Seals standard is VITON with NBR and EPDM available on order. The Operating pressure Range is 0,3 to 16 Bar. Because of the Body Material and Viton seals these valves can be used in with different Liquids and gasses with 99% compatibility. These solenoid valves a good for drinking, potable, medical grade and food grade water or other liquids. The only further requirement is viscosity below 40 Centistokes and a Minimum available pressure of 0,3 Bar (3 Meter Head). Not suitable for Gravity feed applications. These Industrial solenoid valves are fully serviceable, and we have Coils, diaphragms and FULL internal parts kits available. View PDF data sheet for specific information.
|
|
| 1/2" SS316 BSP & VITON seal, Normally closed Valve 0,5 to 16 Bar (C13 Coil excl) | |||||||
| PART NO : PDS22SH15S04 SIZE/DESCRIPTION: 1/2" SS316 BSP & VITON seal, Normally closed Valve 0,5 to 16 Bar (C13 Coil excl) PRICE FROM: R 1930.10 |
|
||||||
| PART NO : PDS22SH20S06 SIZE/DESCRIPTION: 3/4" SS316 BSP & VITON seal, Normally closed Valve 0,5 to 16 Bar (C13 Coil excl) PRICE FROM: R 2283.00 |
|
||||||
| PART NO : PDS22SH25S10 SIZE/DESCRIPTION: 1" One Inch-25mm BSP Normally Closed, SS316 & VITON - 0,5 to 16 Bar (C13 Coil excl) PRICE FROM: R 2925.45 |
|
||||||
| PART NO : PDS22SH40S14 SIZE/DESCRIPTION: 11/2" SS316 BSP & VITON seal, Normally closed Valve 0,5 to 16 Bar (C13 Coil excl) PRICE FROM: R 5652.35 |
|
||||||
| PART NO : PDS22SH50S20 SIZE/DESCRIPTION: 2" SS316 BSP & VITON seal, Normally closed Valve 0,5 to 16 Bar (C13 Coil excl) PRICE FROM: R 7392.20 |
|
||||||
| PNEUMATRON VALVE COILS/SOLENOIDS | |
 |
MATCH YOUR COILS BELOW TO YOUR VALVE TYPE PDS22, P2W22...... |
| PNEUMATRON VALVE COILS/SOLENOIDS | |
|
|
|
MATCH YOUR COILS BELOW TO YOUR VALVE TYPE PDS22, P2W22...... |
|
| C13 Coil & DIN Plug for PLM22, PLM23, PLT32, PLV32, PLV33, PQS22, PDS22. XXX-Specifies Voltage | |||||||
| PART NO : C13DX-XXX SIZE/DESCRIPTION: C13 Coil & DIN Plug for PLM22, PLM23, PLT32, PLV32, PLV33, PQS22, PDS22. XXX-Specifies Voltage PRICE FROM: R 561.10 |
|
||||||
| PART NO : C15DX-XXX SIZE/DESCRIPTION: C15 Coil & DIN Plug for P2W22, P3W23, PLP23, PLA22, PLG22. XXX-Specifies Voltage PRICE FROM: R 614.90 |
|
||||||
| PART NO : C14DX-XXX SIZE/DESCRIPTION: C14 Coil & DIN Plug for P2W22, P3W23, PLP23, PLA22, PLG22. XXX-Specifies Voltage PRICE FROM: R 614.90 |
|
||||||
| PART NO : C12DX-XXX SIZE/DESCRIPTION: 1/2" to 2" PD22 Valves.(XXX Indicates Voltage) PRICE FROM: R 711.40 |
|
||||||
| PART NO : C19DX-XXX SIZE/DESCRIPTION: C19 Coil & DIN Plug for PSM22, PCG23 Valves. XXX-Specifies Voltage PRICE FROM: R 697.70 |
|
||||||
| PART NO : CDHRS 30A-XXX SIZE/DESCRIPTION: CDHRS Coil & Plug for DHD/PD22MH VALVES( 400325-117-1)XXX-Specifies Voltage. PRICE FROM: R 785.25 |
|
||||||
