HIGH PRESSURE SOLENOID VALVES

If you cannot find what you need here then choose a link below(77):

1) Search Tables on Main HOME Page - CLICK HERE

PLZ22 High Pressure Series, Direct Acting (NC) Stainless Solenoid Valve

PLZ22 High Pressure Series - (Pressure is stated for Water & Air -Not applicable for High Viscosity media)(See data sheet for detailed spec).2/2 N/Closed Direct Acting Solenoid Valve. The Valve Body is made of Stainless Steel 316. Seals available is VITON, EPDM, PTFE & PEEK. Orifice 1.5mm, 2mm, 2.5mm & 3mm. See PDF for each valve size pressure range.


View PDF data sheet for specific information.
PLZ22 High Pressure Series, Direct Acting (NC) Stainless Solenoid Valve

PLZ22 High Pressure Series - (Pressure is stated for Water & Air -Not applicable for High Viscosity media)(See data sheet for detailed spec).2/2 N/Closed Direct Acting Solenoid Valve. The Valve Body is made of Stainless Steel 316. Seals available is VITON, EPDM, PTFE & PEEK. Orifice 1.5mm, 2mm, 2.5mm & 3mm. See PDF for each valve size pressure range.


View PDF data sheet for specific information.

1/8" High Pressure Stainless Steel BSP, Viton, Orifice: 2.5mm, 0 to 60Bar (AC) 40Bar (DC) (C17DX coil excl)
PART NO : PLZ22SH025S01V
SIZE/DESCRIPTION:
1/8" High Pressure Stainless Steel BSP, Viton, Orifice: 2.5mm, 0 to 60Bar (AC) 40Bar (DC) (C17DX coil excl)

PRICE FROM: R 1102.90
QUANTITY:


QUANTITY:
PART NO : PLZ22SH015S02V
SIZE/DESCRIPTION:
1/4" High Pressure Stainless Steel BSP, Viton, Orifice: 1.5mm, 0 to 130Bar (AC) 86Bar (DC) (C17DX coil excl)

PRICE FROM: R 1469.15
QUANTITY:


QUANTITY:
PART NO : PLZ22SH02S02V
SIZE/DESCRIPTION:
1/4" High Pressure Stainless Steel BSP, Viton, Orifice: 2mm, 0 to 90Bar (AC) 60Bar (DC) (C17DX coil excl)

PRICE FROM: R 1469.15
QUANTITY:


QUANTITY:
PART NO : PLZ22SH025S02V
SIZE/DESCRIPTION:
1/4" High Pressure Stainless Steel BSP, Viton, Orifice: 2.5mm, 0 to 60Bar (AC) 40Bar (DC) (C17DX coil excl)

PRICE FROM: R 1469.15
QUANTITY:


QUANTITY:
PART NO : PLZ22SH03S02V
SIZE/DESCRIPTION:
1/4" High Pressure Stainless Steel BSP, Viton, Orifice: 3mm, 0 to 30Bar (AC) 20Bar (DC) (C17DX coil excl)

PRICE FROM: R 1476.05
QUANTITY:


QUANTITY:

PLZ22 Brass High Pressure Series for Compressor, N/Closed, Pilot Operated

PLZ22 Brass High Pressure Series for Compressor, N/Closed, Pilot Operated Solenoid Valve. The Valve Body is made of Brass with a PEEK seal. Orifice 8mm. The Operating pressure Range is 1 to 150 Bar.(Pressure is stated for Water & Air -Not applicable for High Viscosity media)(See data sheet for detailed spec).


View PDF data sheet for specific information.
PLZ22 Brass High Pressure Series for Compressor, N/Closed, Pilot Operated

PLZ22 Brass High Pressure Series for Compressor, N/Closed, Pilot Operated Solenoid Valve. The Valve Body is made of Brass with a PEEK seal. Orifice 8mm. The Operating pressure Range is 1 to 150 Bar.(Pressure is stated for Water & Air -Not applicable for High Viscosity media)(See data sheet for detailed spec).


View PDF data sheet for specific information.

3/8" Brass High Pressure BSP, PEEK, Orifice: 8mm, 1 to 150Bar (C17DX coil excl)
PART NO : PLZ22BH08S03K
SIZE/DESCRIPTION:
3/8" Brass High Pressure BSP, PEEK, Orifice: 8mm, 1 to 150Bar (C17DX coil excl)

PRICE FROM: R 2541.50
QUANTITY:


QUANTITY:

PQS22 High Pressure BRASS Series, Diaphragm Direct Acting (N.C), Solenoid Valves

PQS22 High Pressure BRASS Series - 2/2 N/Closed Direct Acting Diaphragm Valves. The Valve Body is made of BRASS with standard VITON seal. The Operating pressure Range differs from orifice size and voltage. Suitable for Gravity feed applications (Zero) 0 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. The only further requirement is viscosity below 20 Centistokes.


View PDF data sheet for specific information.
PQS22 High Pressure BRASS Series, Diaphragm Direct Acting (N.C), Solenoid Valves

PQS22 High Pressure BRASS Series - 2/2 N/Closed Direct Acting Diaphragm Valves. The Valve Body is made of BRASS with standard VITON seal. The Operating pressure Range differs from orifice size and voltage. Suitable for Gravity feed applications (Zero) 0 Bar. Because of the Body Material and seal options these valves can be used in with different Liquids and gasses with 99% compatibility. The only further requirement is viscosity below 20 Centistokes.


View PDF data sheet for specific information.

1/2" BSP, Normally Closed, Brass & Viton, Orifice: 10mm, 0 to 20Bar(AC)/16Bar(DC) (C13DX coil excl)
PART NO : PQS22BH10S04V
SIZE/DESCRIPTION:
1/2" BSP, Normally Closed, Brass & Viton, Orifice: 10mm, 0 to 20Bar(AC)/16Bar(DC) (C13DX coil excl)

PRICE FROM: R 989.05 (Coil Excluded)
QUANTITY:


QUANTITY:
PART NO : PQS22BH13S04V
SIZE/DESCRIPTION:
1/2" BSP, Normally Closed, Brass & Viton, Orifice: 13mm, 0 to 16Bar(AC)/12Bar(DC) (C13DX coil excl)

PRICE FROM: R 989.05 (Coil Excluded)
QUANTITY:


QUANTITY:
PART NO : PQS22BH16S06V
SIZE/DESCRIPTION:
3/4" BSP, Normally Closed, Brass & Viton, Orifice: 16mm, 0 to 12Bar(AC)/10Bar(DC) (C13DX coil excl)

PRICE FROM: R 1156.85 (Coil Excluded)
QUANTITY:


QUANTITY:
PART NO : PQS22BH20S10V
SIZE/DESCRIPTION:
1" BSP, Normally Closed, Brass & Viton, Orifice: 20mm, 0 to 10Bar(AC & DC) (C13DX coil excl)

PRICE FROM: R 1534.50 (Coil Excluded)
QUANTITY:


QUANTITY:

PLG22 High Pressure Series, N/Closed, Stainless Steel Solenoid Valve

PLG22 High Pressure Series, N/Closed, Stainless Steel Solenoid Valves. The Valve Body is made of 304 Stainless Steel. Seals are PTFE. The Maximum Body Pressure is 100 Bar. The Operating Differential Pressure range is 1 to 45 to 75 Bar (See data sheet for detailed spec).( Pressure is stated for Water & Air -Not applicable for High Viscosity media) Temperature up to 110 Deg Celsius. The Specialized Piston Design has PTFE Embedded Ring seals. The guide rings on the piston Isolates the media from the coil.


View PDF data sheet for specific information.
PLG22 High Pressure Series, N/Closed, Stainless Steel Solenoid Valve

PLG22 High Pressure Series, N/Closed, Stainless Steel Solenoid Valves. The Valve Body is made of 304 Stainless Steel. Seals are PTFE. The Maximum Body Pressure is 100 Bar. The Operating Differential Pressure range is 1 to 45 to 75 Bar (See data sheet for detailed spec).( Pressure is stated for Water & Air -Not applicable for High Viscosity media) Temperature up to 110 Deg Celsius. The Specialized Piston Design has PTFE Embedded Ring seals. The guide rings on the piston Isolates the media from the coil.


View PDF data sheet for specific information.

1/2" BSP, High Pressure Stainless Steel 304 & PTFE Piston, 1 to 75 Bar(AC)/55 Bar(DC)-Water & Air(Pressure Not applicable for High Viscosity media). (C14 or C15 coil excl)
PART NO : PLG22SH15S04PT
SIZE/DESCRIPTION:
1/2" BSP, High Pressure Stainless Steel 304 & PTFE Piston, 1 to 75 Bar(AC)/55 Bar(DC)-Water & Air(Pressure Not applicable for High Viscosity media). (C14 or C15 coil excl)

PRICE FROM: R 3102.50
QUANTITY:


QUANTITY:
PART NO : PLG22SH20S06PT
SIZE/DESCRIPTION:
3/4" BSP, High Pressure Stainless Steel 304 & PTFE Piston, 1 to 65 Bar(AC) 50 Bar(DC)-Water & Air(Pressure Not applicable for High Viscosity media). (C14 or C15 coil excl)

PRICE FROM: R 3454.95
QUANTITY:


QUANTITY:
PART NO : PLG22SH25S10PT
SIZE/DESCRIPTION:
1" BSP, High Pressure Stainless Steel 304 & PTFE Piston, 1 to 55 Bar(AC) 45 Bar(DC)-Water & Air(Pressure Not applicable for High Viscosity media). (C14 or C15 coil excl)

PRICE FROM: R 4090.35
QUANTITY:


QUANTITY:

PLGA22 High Pressure Diaphragm Series, N/Closed, Brass Solenoid Valve

PLGA22 High Pressure Diaphragm Series, N/Closed, Brass Solenoid Valve. The Valve Body is made of Brass. Seals are VITON. The Maximum Body Pressure is 50 Bar. (Pressure is stated for Water & Air -Not applicable for High Viscosity media)(See data sheet for detailed spec). Temperature up to 90 Deg Celsius.


View PDF data sheet for specific information.
PLGA22 High Pressure Diaphragm Series, N/Closed, Brass Solenoid Valve

PLGA22 High Pressure Diaphragm Series, N/Closed, Brass Solenoid Valve. The Valve Body is made of Brass. Seals are VITON. The Maximum Body Pressure is 50 Bar. (Pressure is stated for Water & Air -Not applicable for High Viscosity media)(See data sheet for detailed spec). Temperature up to 90 Deg Celsius.


View PDF data sheet for specific information.

1/2" BSP, High Pressure Brass & VITON Diaphragm, 0.5 to 50 Bar-Water & Air(Pressure Not applicable for High Viscosity media). (C17 coil excl)
PART NO : PLGA22BH15S04V
SIZE/DESCRIPTION:
1/2" BSP, High Pressure Brass & VITON Diaphragm, 0.5 to 50 Bar-Water & Air(Pressure Not applicable for High Viscosity media). (C17 coil excl)

PRICE FROM: R 2992.00
QUANTITY:


QUANTITY:

PNEUMATRON HIGH PRESSURE SOLENOID COILS

220VAC Solenoid,24VDC Solenoid,12VDC Solenoid,110VAC Solenoid & 380VAC Solenoid. C13DX Series - Standard F-Type coil to be used on PQS for standard applications. C15DX Series - Standard F-Type coil, mostly DC voltages, to be used on PLG22 for standard applications. C17DX Series - Standard F-Type coil to be used on PLZ22 for standard applications. C20DX Series - Standard F-Type coil to be used on PD5422 for standard applications.

PNEUMATRON HIGH PRESSURE SOLENOID COILS

220VAC Solenoid,24VDC Solenoid,12VDC Solenoid,110VAC Solenoid & 380VAC Solenoid. C13DX Series - Standard F-Type coil to be used on PQS for standard applications. C15DX Series - Standard F-Type coil, mostly DC voltages, to be used on PLG22 for standard applications. C17DX Series - Standard F-Type coil to be used on PLZ22 for standard applications. C20DX Series - Standard F-Type coil to be used on PD5422 for standard applications.


C13 Coil & DIN Plug for PLM22, PLM23, PLT32, PLV32, PLV33, PQS22, PDS22. XXX-Specifies Voltage
PART NO : C13DX-XXX
SIZE/DESCRIPTION:
C13 Coil & DIN Plug for PLM22, PLM23, PLT32, PLV32, PLV33, PQS22, PDS22. XXX-Specifies Voltage

PRICE FROM: R 561.10
QUANTITY:


QUANTITY:
PART NO : C15DX-XXX
SIZE/DESCRIPTION:
C15 Coil & Plug for PLG Solenoid Valve. XXX-Specifies Voltage.

PRICE FROM: R 614.90
QUANTITY:


QUANTITY:
PART NO : C17DX-XXX
SIZE/DESCRIPTION:
C17 Coil & Plug for PLZ22 Solenoid Valve.XXX-Specifies Voltage.

PRICE FROM: R 593.45
QUANTITY:


QUANTITY:
