GENERAL PURPOSE MOTORIZED VALVES

If you cannot find what you need here then choose a link below(70):

1) Search Tables on Main HOME Page - CLICK HERE

Series: PAV2/PAV3/PAC/PXC/PXO/PXD/POMPVC

Loadshedding creates water supply problems and prevents households from pumping from tanks. These PFA and PVC valves allow AUTOMATIC opening/closing without electric power (thus power failure). These Motorized Ball Valves allow a municipal water line to automatically open when power fails, by means of an internal Power Capacitor/Battery system.

The Valves can also be used for backup tank filling and control system from Mains municipal or Borehole.

You can also switch between Solar, Gas or Electric Geyser  as required.

Electric Motorized Ball Valves are used in applications where normal Solenoid Valves fail due to the type of medium (Liquid or Gas) that needs to be controlled. With dirty water or liquids containing big solid pieces the basic diaphragm solenoid valve pilot holes can block.

With an Electric Motor Driven Ball Valve this will not happen, because the drive mechanism is situated outside the valve and does not make contact with the medium. These Valve also uses very little power and for short periods, as the motor switches itself off when the desired position is reached.

The Ball valve is also suitable for gravity feed, low pressure, or vacuum applications, similar to a hand ball valve. The only difference is that this valve is electrically driven by a small geared motor to open and close.

These Motorized Ball Valves are mainly used for applications of domestic water and compressed air. Other applications could include low pressure, borehole/grey water, gravity feed tanks, anti-water hammer or geyser/solar water diversion. These valve are ideal when there is only battery power, because they use about no power when standing still(Open or Closed).

PAV 2 Way Detend Brass - 3 Wire- Electric Ball Valve Series

PAV Series ,2/2 Way Brass Electric Ball Valves Detend (3 Wire Control). This valve Will STAY in the position it was before POWER FAIL. These Valves have switches that switch them off when they reach end of rotation. The PAV valve have metal gears in the gearboxes. The DC Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP54 (NOT WATERPROOF) Body Material Brass Media Pressure: 0-16 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages: AC220V, DC24V, DC12V (See Specific Stock Item) Applications: Recommended usage for clean drinking water (potable water). If you use this valve for grey water, rain water, dam water and borehole water, make sure you have filtration of at least 20 microns before valve inlets. Other non-corrosive CLEAN liquids with a viscosity of less 20 centistokes can also be used. We test these valves to full capacity in our test bench for a minimum of 30 cycles before it is released for sale to ensure good quality.


View PDF data sheet for specific information.
PAV 2 Way Detend Brass - 3 Wire- Electric Ball Valve Series

PAV Series ,2/2 Way Brass Electric Ball Valves Detend (3 Wire Control). This valve Will STAY in the position it was before POWER FAIL. These Valves have switches that switch them off when they reach end of rotation. The PAV valve have metal gears in the gearboxes. The DC Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP54 (NOT WATERPROOF) Body Material Brass Media Pressure: 0-16 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages: AC220V, DC24V, DC12V (See Specific Stock Item) Applications: Recommended usage for clean drinking water (potable water). If you use this valve for grey water, rain water, dam water and borehole water, make sure you have filtration of at least 20 microns before valve inlets. Other non-corrosive CLEAN liquids with a viscosity of less 20 centistokes can also be used. We test these valves to full capacity in our test bench for a minimum of 30 cycles before it is released for sale to ensure good quality.


View PDF data sheet for specific information.

1/2" REDUCED BORE BSP, 2/2 Detend Motorised Brass Ball Valve- XXX Voltage IP54
PART NO : PAV215-XXX
SIZE/DESCRIPTION:
1/2" REDUCED BORE BSP, 2/2 Detend Motorised Brass Ball Valve- XXX Voltage IP54

PRICE FROM: R 1674.65
QUANTITY:


QUANTITY:
PART NO : PAV220-XXX
SIZE/DESCRIPTION:
3/4" REDUCED BORE BSP, 2/2 Detend Motorised Brass Ball Valve- XXX Voltage IP54

PRICE FROM: R 1784.30
QUANTITY:


QUANTITY:
PART NO : PAV225-XXX
SIZE/DESCRIPTION:
1" REDUCED BORE BSP, 2/2 Detend Motorised Brass Ball Valve- XXX Voltage IP54

PRICE FROM: R 1989.05
QUANTITY:


QUANTITY:
PART NO : PAV232-XXX
SIZE/DESCRIPTION:
11/4" REDUCED BORE BSP, 2/2 Detend Motorised Brass Ball Valve- XXX Voltage IP54

PRICE FROM: R 2582.15
QUANTITY:


QUANTITY:
PART NO : PAV240-XXX
SIZE/DESCRIPTION:
11/2" REDUCED BORE BSP, 2/2 Detend Motorised Brass Ball Valve- XXX Voltage IP54

PRICE FROM: R 3144.50
QUANTITY:


QUANTITY:
PART NO : PAV250-XXX
SIZE/DESCRIPTION:
2" REDUCED BORE BSP, 2/2 Detend Motorised Brass Ball Valve- XXX Voltage IP54

PRICE FROM: R 4212.15
QUANTITY:


QUANTITY:

PAV 3 Way Detend Brass - 3 Wire- Electric Ball Valve Series

PAV Series ,3/2 Way Brass Electric Ball Valves Detend (3 Wire Control).This valve Will STAY in the position it was before POWER FAIL. These Valves have switches that switch them off when they reach end of rotation. The PAV valve have metal gears in the gearboxes. The DC Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP54 (NOT WATERPROOF) Body Material Brass Media Pressure: 0-16 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages: AC220V, DC24V, DC12V (See Specific Stock Item) Applications: Recommended usage for clean drinking water (potable water). If you use this valve for grey water, rain water, dam water and borehole water, make sure you have filtration of at least 20 microns before valve inlets. Other non-corrosive CLEAN liquids with a viscosity of less 20 centistokes can also be used. We test these valves to full capacity in our test bench for a minimum of 30 cycles before it is released for sale to ensure good quality.


View PDF data sheet for specific information.
PAV 3 Way Detend Brass - 3 Wire- Electric Ball Valve Series

PAV Series ,3/2 Way Brass Electric Ball Valves Detend (3 Wire Control).This valve Will STAY in the position it was before POWER FAIL. These Valves have switches that switch them off when they reach end of rotation. The PAV valve have metal gears in the gearboxes. The DC Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP54 (NOT WATERPROOF) Body Material Brass Media Pressure: 0-16 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages: AC220V, DC24V, DC12V (See Specific Stock Item) Applications: Recommended usage for clean drinking water (potable water). If you use this valve for grey water, rain water, dam water and borehole water, make sure you have filtration of at least 20 microns before valve inlets. Other non-corrosive CLEAN liquids with a viscosity of less 20 centistokes can also be used. We test these valves to full capacity in our test bench for a minimum of 30 cycles before it is released for sale to ensure good quality.


View PDF data sheet for specific information.

1/2" REDUCED BORE BSP, 3/2 Detend Motorised Brass Ball Valve- XXX Voltage IP54
PART NO : PAV315-XXX
SIZE/DESCRIPTION:
1/2" REDUCED BORE BSP, 3/2 Detend Motorised Brass Ball Valve- XXX Voltage IP54

PRICE FROM: R 1970.05
QUANTITY:


QUANTITY:
PART NO : PAV320-XXX
SIZE/DESCRIPTION:
3/4" REDUCED BORE BSP, 3/2 Detend Motorised Brass Ball Valve- XXX Voltage IP54

PRICE FROM: R 2189.45
QUANTITY:


QUANTITY:
PART NO : PAV325-XXX
SIZE/DESCRIPTION:
1" REDUCED BORE BSP, 3/2 Detend Motorised Brass Ball Valve- XXX Voltage IP54

PRICE FROM: R 2269.90
QUANTITY:


QUANTITY:
PART NO : PAV340-XXX
SIZE/DESCRIPTION:
11/2" REDUCED BORE BSP, 3/2 Detend Motorised Brass Ball Valve- XXX Voltage IP54

PRICE FROM: R 5674.65
QUANTITY:


QUANTITY:

PAC Normally Closed Brass Series- 2 Wire- (SPRING/CAPACITOR RETURN)

PAC Series ,2/2 Way Brass Electric Ball Valves Normally Closed.(2 Wires ONLY- Works Similar like Solenoid Valve and can be wired same). This valve will close when POWER FAILS or when you switch it off.(FAILSAFE/AUTO CLOSE on Power Fail) These Valves have switches that switch them off when they reach end of rotation. The PAC valve have metal gears in the gearboxes. The DC Type uses only milli-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP54 (NOT WATERPROOF) Body Material Brass Media Pressure: 0-16 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages: DC12-24V & AC220V (See Specific Stock Item) Applications: Recommended usage for clean drinking water (potable water). If you use this valve for grey water, rain water, dam water and borehole water, make sure you have filtration of at least 20 microns before valve inlets. Other non-corrosive CLEAN liquids with a viscosity of less 20 centistokes can also be used. We test these valves to full capacity in our test bench for a minimum of 30 cycles before it is released for sale to ensure good quality.


View PDF data sheet for specific information.
PAC Normally Closed Brass Series- 2 Wire- (SPRING/CAPACITOR RETURN)

PAC Series ,2/2 Way Brass Electric Ball Valves Normally Closed.(2 Wires ONLY- Works Similar like Solenoid Valve and can be wired same). This valve will close when POWER FAILS or when you switch it off.(FAILSAFE/AUTO CLOSE on Power Fail) These Valves have switches that switch them off when they reach end of rotation. The PAC valve have metal gears in the gearboxes. The DC Type uses only milli-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP54 (NOT WATERPROOF) Body Material Brass Media Pressure: 0-16 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages: DC12-24V & AC220V (See Specific Stock Item) Applications: Recommended usage for clean drinking water (potable water). If you use this valve for grey water, rain water, dam water and borehole water, make sure you have filtration of at least 20 microns before valve inlets. Other non-corrosive CLEAN liquids with a viscosity of less 20 centistokes can also be used. We test these valves to full capacity in our test bench for a minimum of 30 cycles before it is released for sale to ensure good quality.


View PDF data sheet for specific information.

3/4" FULL BORE BSP, 2/2 Normally Closed Motorised Brass Ball Valve- AC220V IP54
PART NO : PAC220-D1
SIZE/DESCRIPTION:
3/4" FULL BORE BSP, 2/2 Normally Closed Motorised Brass Ball Valve- AC220V IP54

PRICE FROM: R 2479.05
QUANTITY:


QUANTITY:
PART NO : PAC220-D2
SIZE/DESCRIPTION:
3/4" FULL BORE BSP, 2/2 Normally Closed Motorised Brass Ball Valve- DC12-24V IP54

PRICE FROM: R 2479.05
QUANTITY:


QUANTITY:

PXD 5VDC Brass Series Electric Ball Valves (Detent - Polarity Swop)

PXD Series, 2/2 Way Brass Reduced Bore Electric Ball Valve. Voltage Supply is 5VDC with Swop Polarity Control (Detent). These Valves have switches that switch them off when they reach end of rotation. They have metal gears in the gearboxes. The actuator uses only milli-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP40 Body Material Brass Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages: 5VDC Applications: It is used for Domestic Applications or small projects. We test these valves to full capacity for a minimum of 30 cycles before it is released for sale to ensure good quality.


View PDF data sheet for specific information.
PXD 5VDC Brass Series Electric Ball Valves (Detent - Polarity Swop)

PXD Series, 2/2 Way Brass Reduced Bore Electric Ball Valve. Voltage Supply is 5VDC with Swop Polarity Control (Detent). These Valves have switches that switch them off when they reach end of rotation. They have metal gears in the gearboxes. The actuator uses only milli-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP40 Body Material Brass Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages: 5VDC Applications: It is used for Domestic Applications or small projects. We test these valves to full capacity for a minimum of 30 cycles before it is released for sale to ensure good quality.


View PDF data sheet for specific information.

3/4" BSP REDUCED BORE Orf:15mm, 2/2 Detent Motorized Brass Ball Valve 5VDC IP40
PART NO : PXD15BH15S06-W21D05
SIZE/DESCRIPTION:
3/4" BSP REDUCED BORE Orf:15mm, 2/2 Detent Motorized Brass Ball Valve 5VDC IP40

PRICE FROM: R 1384.65
QUANTITY:


QUANTITY:

PFA Brass Series Electric Ball Valves (N/Closed or N/Open)

PFA Series, 2/2 Way Brass Electric Ball Valves. These Valves have switches that switch them off when they reach end of rotation. The valves-(2 Wires ONLY- Works Similar like Solenoid Valve and can be wired same). The N/C Valve will Close when POWER FAILS or when you switch it off (FAILSAFE/AUTO CLOSE on Power Fail). The N/O Valve will Open when POWER FAILS or when you switch it off (FAILSAFE/AUTO OPEN on Power Fail). The DC Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP65 Body Material Brass Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 80 Degrees C. Voltages: DC9-24V & AC110-220V (See Specific Stock Item) Applications: It is used for Domestic Line Shutoff, Home water systems, Solar water heaters and small automatic control equipment. We test these valves to full capacity in our test bench for a minimum of 10 cycles before it is released for sale to ensure good quality.


View PDF data sheet for specific information.
PFA Brass Series Electric Ball Valves (N/Closed or N/Open)

PFA Series, 2/2 Way Brass Electric Ball Valves. These Valves have switches that switch them off when they reach end of rotation. The valves-(2 Wires ONLY- Works Similar like Solenoid Valve and can be wired same). The N/C Valve will Close when POWER FAILS or when you switch it off (FAILSAFE/AUTO CLOSE on Power Fail). The N/O Valve will Open when POWER FAILS or when you switch it off (FAILSAFE/AUTO OPEN on Power Fail). The DC Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP65 Body Material Brass Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 80 Degrees C. Voltages: DC9-24V & AC110-220V (See Specific Stock Item) Applications: It is used for Domestic Line Shutoff, Home water systems, Solar water heaters and small automatic control equipment. We test these valves to full capacity in our test bench for a minimum of 10 cycles before it is released for sale to ensure good quality.


View PDF data sheet for specific information.

3/4'' BSP Electric Ball Valve - Closes when Power fails/OFF,110-220VAC, CR04
PART NO : PFA30-3/4''-N/C-D1
SIZE/DESCRIPTION:
3/4'' BSP Electric Ball Valve - Closes when Power fails/OFF,110-220VAC, CR04

PRICE FROM: R 1960.00
QUANTITY:


QUANTITY:
PART NO : PFA30-3/4''-N/C-D2
SIZE/DESCRIPTION:
3/4'' BSP Electric Ball Valve - Closes when Power fails/OFF 9-24VDC, CR04

PRICE FROM: R 1765.00
QUANTITY:


QUANTITY:
PART NO : PFA30-3/4''-N/O-D1
SIZE/DESCRIPTION:
3/4'' BSP Electric Ball Valve - Opens when Power fails/OFF,110-220VAC, CR04

PRICE FROM: R 1960.00
QUANTITY:


QUANTITY:
PART NO : PFA30-3/4''-N/O-D2
SIZE/DESCRIPTION:
3/4'' BSP Electric Ball Valve - Opens when Power fails/OFF 9-24VDC, CR04

PRICE FROM: R 1765.00
QUANTITY:


QUANTITY:
