POM50 ON/OFF Actuator 50Nm, Rotation Time varies from 20 to 25 Seconds depending on voltage, with ISO5211 Mounting Standard. Supply voltages AC220V or DC24V. PVPOM50 Proportional Control Actuator 50Nm, Control Signal 4-20mA, Supply Voltages AC220V or DC24V. ISO5211 Mounting Standard. Valve Builds available with 3 Piece Stainless Steel Ball Valve Bodies or Wafer Butterfly Valves. The POM50 & PVPOM50 actuators come with a position indicator on top of the actuator, it also has End Position Feedback Signal to remotely see the position status of the actuator. The actuator also has internal limited switches to stop the motor once the actuator has reached fully open or fully closed position.

View PDF data sheet for specific information.

POM1(50Nm), POM2(100Nm), POM3(500Nm) ON/OFF Actuators, Rotation Time varies from 10 to 30 Seconds depending on Actuator Type and Voltage, these actautors have ISO5211 Mounting Standard. Supply voltages AC220V or DC24V. For the Proportional Control Actuators Control Signal 4-20mA, Supply Voltages AC220V or DC24V. Valve Builds available with 3 Piece Stainless Steel Ball Valve Bodies or Wafer Butterfly Valves. The POM1/2/3 actuators come with a Position Indicator on top of the actuator, it also has End Position Feedback Signal to remotely see the position status of the actuator. The actuator has internal limited switches to stop the motor once the actuator has reached fully open or fully closed position.

View PDF data sheet for specific information.

PVP2XX Series, 2/2 Way Stainless Steel FULL BORE Proportional Electric Ball Valves. These Valves open proportionally as the control signal increases from 4mA (Closed) to Fully open at (20mA). The DC Type uses only mili-amps, during movement time to open and close and can thus be used for months or years on small batteries.(Ideal for remote control) Features: Motor Enclosure:IP65 Body Material Stainless Steel 304 PTFE Ball seals and FKM(viton) stem seals Media Pressure: 0-10 Bar Medium temperature: Minus 2 to 95 Degrees C. Voltages: DC12-24V Control signal: 4-20mA Standard.

View PDF data sheet for specific information.

POM20 Plastic Electric Actuator 25Nm, 15 seconds rotation, with ISO5211 Mounting Standard. Supply voltage AC220V/DC24V/AC24V/DC12V with End Position Feedback. See data sheet for wiring diagram. Valve bodies available in PVC or PPH - 1"(25mm) or 2"(50mm). This Actuator have switches that switch it off when it reaches end of rotation. All Actuators have Potential Free Position Feedback Terminals available to remotely see valve open or closed with lights or to connect to PLC (Programmable Logic controller). Features: Motor Enclosure:IP67 Medium temperature: Minus 20 to 60 Degrees C. Voltages: 220VAC or 24VDC or 24VAC or 12VDC

View PDF data sheet for specific information.

POM30Plastic Electric Actuator 35Nm, 15 seconds rotation, with ISO5211 Mounting Standard. Supply voltage AC220V or DC24V or 24VAC with End Position Feedback. See data sheet for wiring diagram. Valve bodies BSP Threaded inserts- available in PVC - 21/2"(65mm),3"(80mm) or 4"(100mm). This Actuator have switches that switch it off when it reaches end of rotation. All Actuators have Potential free Position feedback Terminals available to remotely see Valve open or closed with lights or to connect to PLC (Programmable Logic controller) Features: Motor Enclosure:IP67 Medium temperature: Minus 20 to 60 Degrees C. Voltages: 220VAC or 24VAC or 24VDC

View PDF data sheet for specific information.
